A group of researchers from Canada’s Research Center for High Performance Polymer and Composite Systems (CREPEC) at the Polytechnique MontrÃ©al recently submitted a paper, titled “3D Printing of Self-Healing and Stretchable Nanocomposites Sensors,” in Materials Horizons that explains how they developed a self-healing nanocomposite, made of chitosan (CS) and carbon nanotubes (CNT), that can heal damage once it’s exposed to water vapor at room temperature.
The abstract reads, “In this work, we report a novel multifunctional material with self-healing ability and electrical conductivity based on chitosan (CS) and multiwall carbon nanotubes (CNT) (30 wt%). The self-healing of the nanocomposites can be achieved with the assistance of water vapor. The self-healing process is rapid, occurring within seconds to heal the damage. Upon drying, the conductivity can be restored. The nanocomposite is processed by instability-assisted 3D printing at room temperature for producing highly tunable microstructured fibers. The microstructured fibers featuring sacrificial bonds and hidden lengths endow the nanocomposite with high stretchability (strain at break of 180%). Exposure the CS/CNT microstructured fibers to water vapor can restore their mechanical properties (e.g., flexibility, strength and toughness) after healing their broken sacrificial bonds. Granted with properties such as self-healing, stretchability and conductivity, CS/CNT nanocomposite strain sensor are developed to detect human elbow motion and local deformation.”
There are many applications for stretchable, self-healing devices made from sustainable materials, such as biomedical devices, soft robotics, and wearable sensors, because of their restorative properties and low cost. But, due to an increasing demand for more powerful electronics, electronic waste that contains non-biodegradable and toxic materials is a big problem. While there has been research conducted on designing self-healing materials based on autonomic healing, among other features, they can’t really be used in electronics due to a lack of electrical conductivity.
“It remains a challenge to combine eco-friendly material, easy processing, fast and repeatable healing properties, high stretchability and complex structures into material design for electronic applications,” the researchers wrote.
The team turned to 3D printing, which is a low-cost way to accurately fabricate electronic devices. While it’s necessary to have a high loading (20 wt %) of CNTs to make a conductive nanocomposite, this level of concentration in the polymer binder lowers the stretchability. Instability-assisted 3D printing (IA3DP) of PLA fibers, however, can improve this property for polymers.
“Here, we report a self-healing chitosan (CS)/carbon nanotubes (CNT) nanocomposite that is able to heal damage under exposure to water vapor at room temperature. The nanocomposite can be fabricated with microstructured fibers featuring sacrificial bond and hidden length by instability-assisted 3D printing (IA3DP). The resultant as-printed CS/CNT structure retains its hierarchical architecture and exhibits excellent mechanical properties,” the researchers wrote. “A conductivity as high as ~ 1450 S/m was measured, which is higher than previously reported chitosan-based CNT nanocomposites (e.g., ~ 500 S/m).35-37 The microstructure of completely or partially broken CS/CNT fibers (e.g., cut straight fibers or broken sacrificial bonds in microstructured fibers) can be restored, as well as their electrical and mechanical properties after exposing to water vapor. This water-vapor triggered nanocomposite allows processing multidimensional architectures and develop functional sensors that are capable of sensing humidity and strain.”
The team developed a novel CS/CNT ink, made up of a blend of CNTs, CS as polymer binder, and a dispersing solution of distilled water and acetic, citric, and lactic acids. Then, the ink was used to make complex 3D structures and microstructured fibers with a combination of IA3DP and solvent-cast 3D printing (SC3DP).
The researchers performed electrical conductivity tests on fibers of the CS/CNT nanocomposites, in addition to mechanical tests on both straight and coil-patterned fibers.
In order to test the seal-healing behavior, the team cut the CS/CNT fibers with a standard razor blade, and then sprayed water vapor on the samples for 10 seconds. A humidifier was then used to heal the cut fibers, and then they were dried by a hair dryer until “the current back to the initial values.”
The researchers then performed electrical measurements on both the original and healed fibers.
The team’s work is already shedding more light on using high stretchability and self-healing ability in sensor design. In addition, the paper is showcasing the use of biodegradable polymers that “leads to a class of electronic materials for excellent performance and functionality of electronic devices.”
“By applying structural hierarchy, microstructured fiber with sacrificial bond and hidden length endow a high stretchability (maximum strain of 180 %) of the CS/CNT nanocomposite with a high CNT content (30 wt %). This room-temperature processed, fast and repeatable self-healing electronic nanocomposite material can restore its outstanding mechanical properties (i.e., stretchability, strength and toughness) and high electrical conductivity by simply applying water vapor,” the researchers concluded. “These CS/CNT nanocomposite instability-assisted 3D printed structures can be designed as multifunctional devices including humidity and strain sensors. The humidity sensor presents a reversible sensing ability and strain sensors are capable of sensing human motion and local deformation. The restoration of nanocomposite shape and electrical properties can be achieved either through structure design (e.g., using flexible supportive substrate) or the healing properties of nanocomposites. This work not only develops a simple strategy to design CS/CNT nanocomposites with self-healing properties, but also demonstrates the 3D printing of multidimensional structures as well as the development of strain sensor applications.”
Co-authors are Qinghua Wu, Shibo Zou, FrÃ©dÃ©rick Gosselin, Daniel Therriault, and Marie-Claude Heuzey.
